A multifunctional CNC five axis machine, carving, cutting, drilling, etc., is worth buying

CNC 5 axis Processing Center Router Machine,Five-axis CNC milling machine will be sold to the world,5 axis cnc machine Suppliers and Manufacturers in China. Contact number:+86-15618857188,E-mail address:rscncrouter@gmail.com

Chinese manufacturer of CNC five axis machining center, detail display of CNC five axis machine:



5 Axis CNC Processing Center Router Machine is a profesional stable good quality multi axis cnc 5 axis router, it is ready for production cutting, drilling, trimming, as well as prototype-and fixture-machining in a large work envelope, accessible from all angles. High class 5 aixs is a very high price machine, but now you will have a good price for this kind of machines, we are sure this can help you create more.


webwxgetmsgimg (12).jpg

webwxgetmsgimg (13).jpg

webwxgetmsgimg (14).jpg

webwxgetmsgimg (15).jpg

webwxgetmsgimg (16).jpg

webwxgetmsgimg (17).jpg

Because of the high price for 5 axis system, we choose wordwide good brand system for this machine, 5 axis moving Axis. Supply the post, customers will be easy to update, we have suitable high price version, but if customers can do all by yourself, this is a good machine to run.



Series

RECOJI2500

Travelling Size

2860*3560*1000mm

Working Size

2500*3000*850mm

Table size

3250*5250mm

Transmission

X/Y rack and pinion drive,Z ball screw drive, A and B   axis with robot gears

A and B axis moving range

A and B: -120 degree to +120 degress

Motion Parts

All axes with linear guides

Table structure

Aluninum T slot table

Spindle Power

3.7;5.5;9KW (Option: customized by customers) Italy   INTEGRATED 5axis head

Spindle speed

24000 r/min

Travelling Speed

60m/min

Working speed

35m/min

Tool

ER

Driving system

Japanese AC servo

Voltage

AC380V/3PH/50HZ (Option: customized by customers)

Controller

Syntec 5axis system with RTCP

webwxgetmsgimg (1).jpg
